SUPERMICRO 1U BARE 1XEON E3V6 C236 4X3.5HS 350WR 64GB SATA3 2X10GBE 1PCIE BARE
You have to log in to shop/see prices.
|
|
SUPERMICRO 1U BARE 1XEON E3V6 C236 4X3.5HS 350WR 64GB SATA3 2X10GBE 1PCIE BARE
-
Type
Rack (1U)
-
CPU family
Intel
-
CPU
-
-
Number of processors installed
0
-
Max CPU
1
-
Max Disks
4
-
Installed Memory
0GB
-
Max Memory
64GB
-
Redundant PSU
No
-
CTO / BTO
No
|
Description
Specifications
SuperServers are Your Best Choice!
SuperServer Benefits:
- Uncompromising Quality Control
- The most Comprehensive Line of Servers, Storage Systems, and Subsystems
- Widest Variety of Application Optimized Solutions, from High End Clusters to MicroServers
- Best Performance per-Watt, per-Square-Foot, and per-Dollar
- Superior Product Design Based in Silicon Valley
- Consistently First-to-Market
- Best Total Cost of Ownership (TCO)
- Highest Quality Components and Materials
- 3-Year Limited Warranty
- 24-Hour Support and Global Services
- Redfish API support
These benefits combined with an excellent track record have earned Supermicro a reputation as a true leader in the high-end server/storage industry. Supermicro provides the most outstanding product line in the industry, ranging from single Atom™ and dual Xeon® to quad Xeon® MP systems. Their proven high level of quality and performance has made SuperServers the platform of choice for HPC, enterprise, cloud, data center, hyperscale, embedded, and business-critical, front-end server applications.
| Motherboard chipset | Intel® C612 |
| Processor socket | LGA 1151 (Socket H4) |
| Processor family | Intel |
| Number of processors supported | 1 |
| Compatible processor series | Intel® Core™ i3 |
| Intel Xeon series | E3-1200 |
| Number of DIMM slots | 4 |
| Supported memory types | DDR4-SDRAM |
| Supported DIMM module capacities | 4GB, 8GB, 16GB |
| Maximum UDIMM memory | 64 GB |
| Supported UDIMM clock speeds | 1600,1866,2133 MHz |
| Memory form factor | 288-pin DIMM |
| Memory voltage | 1.2 V |
| Memory bus | 72 bit |
| ECC | Yes |
| Number of storage drives supported | 4 |
| Hot-swap HDD bays | Yes |
| Storage drive sizes supported | 2.5,3.5" |
| Supported storage drive interfaces | Serial ATA III |
| RAID levels | 0,1,5,10 |
| On-board graphics adapter model | Aspeed AST2400 |
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 100,1000,10000 Mbit/s |
| Copper ethernet cabling technology | 10GBASE-T,100BASE-TX,1000BASE-T |
| LAN controller | Intel® X550 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| IPMI LAN (RJ-45) port | Yes |
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 1 |
| Number of SATA III connectors | 4 |
| PCI Express slots version | 3.0 |
| PCI Express x8 slots | 1 |
| PC health monitoring | Fan, LED, Temperature, Voltage |
| Sustainability certificates | RoHS |
| Intelligent Platform Management Interface (IPMI) support | Yes |
| BIOS type | AMI |
| BIOS memory size | 64 Mbit |
| ACPI version | 2.0 |
| BIOS features | PCI 2.3,SMBIOS 2.3 |
| Chassis type | Rack (1U) |
| Product colour | Black |
| LED indicators | HDD, Network, Power |
| On/off switch | Yes |
| Rack-Friendly board | Yes |
| Number of fans | 4 fan(s) |
| Fan diameter | 2.8 cm |
| Power supply | 350 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 4.2 - 1.8 A |
| DC output current (+5 V) | 12 A |
| DC output current (+12 V) | 29 A |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Width | 437 mm |
| Depth | 503 mm |
| Height | 43 mm |
| Weight | 8 kg |
